Final Filters Delivered for Rubin Observatory Camera

Lawrence Livermore National Laboratory optical engineers Justin Wolfe (left) and Simon Cohen hold up the r filter for Vera C. Rubin Observatory’s LSSTCam. Assembly technician Frank Arredondo appears in the filter’s reflection. Credit: LLNL/G. McLeod

After nearly a decade of work, Lawrence Livermore National Laboratory (LLNL) has delivered the last of the six filters built for use with Vera C. Rubin Observatory’s Legacy Survey of Space and Time Camera (LSSTCam). The filters have now all arrived at the US Department of Energy’s SLAC National Accelerator Laboratory, where they will be integrated into the camera.

“We’re all very excited,” said LLNL engineer Vincent Riot, who has been the Rubin LSSTCam camera manager for the past four years. “The optical lenses and filters have been a long time in the making. This project has been under way for about 10 years. Now, we’ll soon see the integration of all of the camera’s components as part of the telescope’s commissioning.”

The six filters were fabricated using glass raw material from the state of New York, which was shipped to Thales Space SESO in France. Thales Space SESO shaped and polished the glass into the optical filters between 2016 and 2020. The filters were then transported to Materion, based in Massachusetts, which coated the glass on all six filters in a special chamber built especially for coating the LSSTCam filters.

The 3200-megapixel LSSTCam will be the largest digital camera ever built. In turn, the six LSSTCam filters are some of the largest optical filters ever produced. Each filter is about 76 centimeters (30 inches) wide and weighs about 40 kilograms (90 pounds), ranging in thickness from 13 millimeters (about a half inch) to 26 millimeters (one inch).

The filters are labeled ugriz, and y. Each transmits light from a segment of the electromagnetic spectrum, progressing throughout the entire visible range and moving from the near-ultraviolet (u) to the near-infrared (y). The u filter was the final one LLNL delivered to SLAC.

Using the LSSTCam, the 8.4-meter telescope at Rubin Observatory will image the entire sky visible from its location on Cerro Pachón in Chile every few nights, revealing unprecedented details of the Universe and helping unravel some of its greatest mysteries.
